Modern industrial automation systems are becoming increasingly complex, demanding precise timing and deterministic behavior. Real-time responsiveness is crucial for tasks like motion control, robotics, and process automation, where even small delays can lead to significant production losses or safety hazards. Traditional operating systems often struggle to meet these stringent real-time requirements, leading to unpredictable performance and potential system failures. Let's explore the challenges of achieving real-time responsiveness in industrial automation and how SYSGO's PikeOS real-time operating system (RTOS) provides a robust solution.

Challenges of Real-Time in Industrial Automation

Industrial automation systems face several challenges when it comes to real-time performance:

• Timing Constraints: Tasks must be executed within strict deadlines. Missing a deadline can have catastrophic consequences, such as a robotic arm colliding with equipment or even people.
• Concurrency: Multiple tasks, such as sensor data acquisition, control algorithms, and communication, must run concurrently and often interact with each other. Managing these concurrent tasks efficiently and predictably is crucial.
• Resource Management: CPU time, memory, and I/O resources must be allocated and managed carefully to ensure that critical tasks receive the necessary resources when they need them.
• Safety and Reliability: Industrial systems often operate in hazardous environments and must be highly reliable. A software failure can lead to safety incidents or costly downtime.
• Integration Complexity: Modern automation systems often integrate components from different vendors, each with its own software and hardware. Ensuring seamless integration and predictable real-time behavior across these heterogeneous systems can be a major challenge.

SYSGO's PikeOS: A Solution for Real-Time Industrial Automation

PikeOS is a real-time operating system specifically designed for safety-critical and time-sensitive applications. It offers several features that address the challenges of real-time in industrial automation:

• Partitioning: PikeOS employs a partitioning architecture, which isolates different tasks and prevents them from interfering with each other. This ensures that critical tasks, such as motion control, are protected from less critical tasks, such as data logging. If one partition fails, the other partitions are not affected, improving system reliability.
• Priority-based Scheduling: PikeOS provides a priority-based scheduler that allows developers to assign priorities to different tasks. This ensures that the most critical tasks are always executed first. The scheduler is deterministic, guaranteeing predictable execution times.
• Safety Certification: PikeOS is certified to multiple industry safety standards, including IEC 61508 for industrial applications. This and other certifications make it a trusted choice for safety-critical applications across various industries.
• Resource Management: PikeOS provides mechanisms for managing system resources, such as CPU time, memory, and I/O. Developers can allocate resources to specific partitions, ensuring that critical tasks have the resources they need.
• Support for multiple Architectures: PikeOS supports a wide range of processor architectures, including ARM, x86, PowerPC and RISC-V. This provides flexibility for developers to choose the hardware that best meets their needs.

Real-Time Use Cases and Benefits

• Robotics and COBOTs: In robotic applications, PikeOS ensures precise and deterministic control of robot movements, enabling high-speed and accurate operations. The partitioning feature is crucial for isolating the control algorithms from other tasks, ensuring that the robot responds quickly to sensor inputs.
• Motion Control: PikeOS provides the real-time performance needed for high-precision motion control systems. Its deterministic scheduling ensures that motor commands are executed at the correct time, resulting in smooth and accurate movements.
• Process Automation: In process automation, PikeOS enables real-time monitoring and control of industrial processes. Its partitioning feature ensures that critical control loops are not affected by other tasks, preventing process disruptions.
• Safety Systems: PikeOS is ideal for implementing safety systems in industrial environments. Its isolation capabilities and deterministic behavior ensure that safety functions are executed reliably, even in the event of a software failure.

Conclusion & Future Outlook

Real-time responsiveness is essential for many industrial automation applications. SYSGO's PikeOS RTOS provides a robust and reliable solution for achieving real-time performance in these demanding environments. Its partitioning architecture, priority-based scheduling, and resource management capabilities enable developers to build complex systems that meet stringent timing requirements and safety standards.

As industrial automation systems become even more complex and interconnected, the need for real-time performance will continue to grow. Future developments will focus on enhancing scalability, security, and connectivity features to meet the evolving needs of the industrial automation market. This includes supporting new communication protocols, integrating with cloud-based systems, and enhancing security features to protect against cyberattacks. SYSGO offers powerful tools and technologies that simplify the development and deployment of real-time applications, making it easier for customers to build and maintain their industrial automation systems.
